Pimax 5K Super

Pimax 5K Super

Per-eye resolution
Horizontal FoV
PC Powered
Pimax 5K Super
Manufacturer Pimax
Device Type PC powered
Platform SteamVR, Oculus Home
Announced 2020-01-01
Release Date 2020-12-01
Retail Price $749 headset only
$1049 with controllers
$1299 with controllers, base stations
Display Type 2 x CLPL
Subpixel Layout RGB stripe
Resolution (per eye) 2560x1440
Refresh Rate 180 Hz
Field of View 150° horizontal, 103° vertical, 182° diagonal*
Advertised as 170° (H), 115° (V), 200° (D)
Passthrough No
IPD Range 60-72 mm hardware adjustable
(excluding headstrap)
280 x 108 x 136 mm
11.02 x 4.25 x 5.35 in
Weight 500 g without headstrap
750 g with headstrap
Material Plastic, foam facial interface
Headstrap Hard padded modular audio strap (Pimax SMAS)
Colors Blue
Tracking Type 6 DoF Inside-out (marker based)
Base Stations 2 x SteamVR 2.0
Eye Tracking No
Face Tracking No
Hand Tracking No
Body Tracking No
Controllers 2 x Index Controller (6 DoF)
Weight 196 g
Input Methods Trackpad, face buttons, index trigger
Finger Tracking Full thumb and finger tracking
Haptics Yes
Controller Batteries Rechargable
Battery Life 8 hours
Speakers Integrated in-strap stereo speakers
Microphone Yes
3.5mm Audio Jack Yes
Ports No
Video Connection DisplayPort 1.4, USB 3.0
WiFi No
Bluetooth No
Other No


The Pimax 5K Super is a virtual reality headset manufactured by Pimax. It was released in December 2020, following an announcement in January the same year. It is the company's seventh VR headset release.

- This headset requires a connection to a PC in order to be used.

- This headset is heavy. 750 g

- This headset has a high per-eye resolution. 2560x1440

- This headset has a high refresh rate. 180 Hz

- This headset has a high horizontal field of view. 150°

- This headset uses marker-based tracking that requires external base stations for full tracking capability.

- This headset can be purchased with two 6DoF controllers.

The Pimax 5K Super is the first VR headset to achieve a refresh rate of 180 Hz. It currently has the highest refresh rate available in a VR headset. This position was previously shared between Pimax's 5K Plus and the Valve Index, both of which run displays at 144 Hz.

controllers Index Controller, sold alongside the headset
